Ceph Debugging on Proxmox: Essential Commands and Troubleshooting

When running Ceph on Proxmox, issues can arise at any layer of the storage stack. Knowing the right commands to diagnose and resolve problems is essential for maintaining a healthy cluster. This guide covers the most useful Ceph commands for debugging and troubleshooting on Proxmox.

Cluster Health and Status

The first step in any troubleshooting session is to check the overall cluster health.

ceph -s

This shows a summary including health status, OSD/MON/MGR counts, I/O rates, and placement group states. For more detailed health information:

ceph health detail

To check disk usage across pools:

ceph df

OSD Diagnostics

OSDs (Object Storage Daemons) are often the source of issues. Start by viewing the hierarchical layout:

ceph osd tree

Check the up/in status of all OSDs:

ceph osd status

For detailed usage information including space and performance weight:

ceph osd df

List all storage pools:

ceph osd pool ls

Get per-pool statistics for performance monitoring:

ceph osd pool stats

OSD Maintenance Operations

When performing maintenance on an OSD, mark it out first:

ceph osd out osd.3

After maintenance, bring it back into the cluster:

ceph osd in osd.3

To manually adjust an OSD’s relative data weight:

ceph osd crush reweight osd.2 0.8

Monitor and Manager Status

For troubleshooting monitor quorum issues:

ceph quorum_status

Check the manager daemon status and enabled modules:

ceph mgr dump

Placement Groups (PGs)

Placement groups are fundamental to Ceph’s data distribution. Check their state:

ceph pg stat

For detailed information about all placement groups:

ceph pg dump

List PGs belonging to a specific pool:

ceph pg ls-by-pool <POOL-NAME>

RBD Pool and Image Management

List RBD images in a pool:

rbd ls -p vm-storage

Show details of a specific block image:

rbd info -p vm-storage vm-100-disk-0

List all snapshots for a given image:

rbd snap ls vm-100-disk-0

Resize an image (expand only):

rbd resize vm-100-disk-0 --size 20480

Performance Testing and Maintenance

Benchmark all OSDs to identify performance bottlenecks:

ceph tell osd.* bench

Manually trigger a scrub on an OSD for data consistency checks:

ceph osd scrub osd.0

Check if automatic balancing is active:

ceph balancer status

Enable optional manager modules:

ceph mgr module enable dashboard

Authentication and Keyring Management

List all Ceph authentication keys:

ceph auth list

Get a specific client’s authentication key:

ceph auth get client.admin

Remove a client key:

ceph auth del client.radosgw.pve1

Cleanup and Decommissioning

Completely remove an OSD from the cluster:

ceph osd purge osd.3 --yes-i-really-mean-it

Remove a monitor that has been physically removed or decommissioned:

ceph mon remove mon.pve3

Proxmox-Specific Commands

Proxmox provides wrapper commands that integrate with its configuration system:

pveceph status
pveceph pool ls
pveceph osd create /dev/sdb
pveceph install --version quincy

These commands help maintain UI synchronization and work with Proxmox’s configuration files.

Ceph Dashboard Installation

The Ceph dashboard provides a web-based interface for monitoring and managing your cluster.

Install Dashboard Package

Run on all manager nodes:

apt install ceph-mgr-dashboard -y

Enable Dashboard Module

Run on any manager node:

ceph mgr module enable dashboard
ceph mgr module ls | grep dashboard  # Verify

SSL Configuration

For a quick homelab setup, disable SSL:

ceph config set mgr mgr/dashboard/ssl false
ceph mgr module disable dashboard
ceph mgr module enable dashboard

For production, use manual SSL setup:

# Generate self-signed certificate
openssl req -newkey rsa:2048 -nodes -x509 \
  -keyout /root/dashboard-key.pem \
  -out /root/dashboard-crt.pem \
  -sha512 -days 3650 \
  -subj "/CN=IT/O=ceph-mgr-dashboard" -utf8

# Install certificates
ceph config-key set mgr/dashboard/key -i /root/dashboard-key.pem
ceph config-key set mgr/dashboard/crt -i /root/dashboard-crt.pem

# Enable SSL and restart
ceph config set mgr mgr/dashboard/ssl true
ceph mgr module disable dashboard
ceph mgr module enable dashboard

Create Admin User

For homelab environments, disable password policies:

ceph dashboard set-pwd-policy-check-complexity-enabled false
ceph dashboard set-pwd-policy-enabled false

Create the admin user:

echo "admin" > ./password
ceph dashboard ac-user-create admin -i ./password administrator --force

Access the Dashboard

Get the dashboard URL:

ceph mgr services

Access via https://<proxmox-node>:8443/#/dashboard with username admin and your configured password.

Note: The dashboard runs on the node with the active ceph-mgr. The URL may change on failover.

Quick Troubleshooting Workflow

When issues arise, follow this systematic approach:

1. Check cluster health - Start with ceph -s or ceph health detail
2. Identify problematic OSDs - Use ceph osd tree and ceph osd status
3. Check disk usage - Run ceph df and ceph osd df
4. Review PG states - Execute ceph pg stat to find stuck placement groups
5. Perform maintenance - Use ceph osd out before work, then ceph osd in after
6. Benchmark performance - Run ceph tell osd.* bench to identify slow OSDs

Common Issues and Solutions

OSD Marked Out Unexpectedly

If an OSD is marked out without intervention, check the logs:

journalctl -u ceph-osd@osd.0 -f

Placement Groups Stuck

PGs stuck in degraded or undersized state often indicate OSD failures. Use ceph pg dump to identify affected groups and their OSDs.

Monitor Quorum Loss

If monitors lose quorum, check network connectivity between nodes and verify monitor health with ceph quorum_status.

Slow Performance

Use ceph osd df to identify imbalanced OSDs and ceph tell osd.* bench to benchmark individual daemons. Consider enabling the balancer module for automatic rebalancing.

Conclusion

Mastering these Ceph commands will significantly reduce troubleshooting time on your Proxmox cluster. The key is to start with high-level health checks and progressively drill down to specific components. Regular monitoring and understanding normal cluster behavior will help you quickly identify when something deviates from the expected state.

For ongoing monitoring, consider enabling the Ceph dashboard for a visual overview of cluster health, performance metrics, and management capabilities. However, command-line tools remain essential for deep debugging and automation scenarios.
