Kubernetes integration with external Vault

June 05, 2021

Kubernetes

Page content

In this post I will show you how you can integrate an external HashiCorp Vault to Kubernetes.

Parts of the K8S Security Lab series

Vhat is Hashicorp Vault

HashiCorp Vault is a secrets management solution that brokers access for both humans and machines, through programmatic access, to systems. Secrets can be stored, dynamically generated, and in the case of encryption, keys can be consumed as a service without the need to expose the underlying key materials.

Example image

K3s install

ssh-copy-id vagrant@172.17.8.101

k3sup install \
  --ip=172.17.8.101 \
  --user=vagrant \
  --sudo \
  --tls-san=172.17.8.100 \
  --cluster \
  --k3s-channel=stable \
  --k3s-extra-args "--no-deploy=traefik --flannel-iface=enp0s8 --node-ip=172.17.8.101" \
  --merge \
  --local-path $HOME/.kube/config \
  --context=k3s-ha

Install vault

sudo dnf install -y dnf-plugins-core nano jq

cp /etc/rancher/k3s/k3s.yaml ~/.kube/config

sudo dnf config-manager --add-repo https://rpm.releases.hashicorp.com/RHEL/hashicorp.repo
sudo dnf install -y vault

nano /etc/vault.d/vault.hcl
# HTTP listener
listener "tcp" {
  address = "0.0.0.0:8200"
  tls_disable = 1
}

# HTTPS listener
#listener "tcp" {
#  address       = "0.0.0.0:8200"
#  tls_cert_file = "/opt/vault/tls/tls.crt"
#  tls_key_file  = "/opt/vault/tls/tls.key"
#}

api_addr         = "http://0.0.0.0:8200"

systemctl start vault
systemctl enable vault

vault -autocomplete-install
complete -C /usr/bin/vault vault

export VAULT_ADDR=http://127.0.0.1:8200
echo "export VAULT_ADDR=http://127.0.0.1:8200" >> ~/.bashrc

vault status

vault operator init | tee /opt/vault/init.txt
Unseal Key 1: t4PsGsw8cj25l9tSpvh2Avr5647HhdaI27aAzSiYJz0=

Initial Root Token: s.sPKauYvv9iFKliclTIaMgbU1

export VAULT_TOKEN="s.sPKauYvv9iFKliclTIaMgbU1"

vault operator unseal t4PsGsw8cj25l9tSpvh2Avr5647HhdaI27aAzSiYJz0=

vault auth enable userpass
vault write auth/userpass/users/devopstales \
    password=Password1 \
    policies=admins

Integrate a Kubernetes Cluster with an External Vault

https://3p8owy1gdkoh452nrc36wbnp-wpengine.netdna-ssl.com/wp-content/uploads/2018/12/nirmata-vault-7-1024x623.png

vault secrets enable kv

vault kv put kv/secret/devwebapp/config username='giraffe' password='salsa'

vault kv get -format=json kv/secret/devwebapp/config | jq ".data"

# create policy
vault policy write devwebapp-kv-ro - <<EOF
path "kv/secret/devwebapp/*" {
    capabilities = ["read", "list"]
}
EOF

# create Kubernetes ServiceAccount
cat > internal-app.yaml <<EOF
apiVersion: v1
kind: ServiceAccount
metadata:
  name: devwebapp
---
  apiVersion: rbac.authorization.k8s.io/v1
  kind: ClusterRoleBinding
  metadata:
    name: role-tokenreview-binding
    namespace: default
  roleRef:
    apiGroup: rbac.authorization.k8s.io
    kind: ClusterRole
    name: system:auth-delegator
  subjects:
  - kind: ServiceAccount
    name: devwebapp
    namespace: default
EOF

kubectl apply --filename internal-app.yaml

export EXTERNAL_VAULT_ADDR=172.17.8.101
export K8S_HOST=172.17.8.101

export VAULT_SA_NAME=$(kubectl get sa devwebapp \
    -o jsonpath="{.secrets[*]['name']}")

export SA_JWT_TOKEN=$(kubectl get secret $VAULT_SA_NAME \
    -o jsonpath="{.data.token}" | base64 --decode; echo)

export SA_CA_CRT=$(kubectl get secret $VAULT_SA_NAME \
    -o jsonpath="{.data['ca\.crt']}" | base64 --decode; echo)

vault auth enable kubernetes

vault write auth/kubernetes/config \
  issuer="https://kubernetes.default.svc.cluster.local" \
  token_reviewer_jwt="$SA_JWT_TOKEN" \
  kubernetes_host="https://$K8S_HOST:6443" \
  kubernetes_ca_cert="$SA_CA_CRT"

vault write auth/kubernetes/role/devwebapp \
        bound_service_account_names=devwebapp \
        bound_service_account_namespaces=default \
        policies=devwebapp-kv-ro \
        ttl=24h

INstall Vault Agent Injector

dnf copr enable cerenit/helm -y
dnf install helm -y

helm repo add hashicorp https://helm.releases.hashicorp.com
helm repo update

### változók???
helm install vault hashicorp/vault \
    --set "injector.externalVaultAddr=http://$EXTERNAL_VAULT_ADDR:8200"

Demo

cat > devwebapp.yaml <<EOF
---
apiVersion: apps/v1
kind: Deployment
metadata:
  name: orgchart
  labels:
    app: orgchart
spec:
  selector:
    matchLabels:
      app: orgchart
  replicas: 1
  template:
    metadata:
      annotations:
        vault.hashicorp.com/agent-inject: "true"
        vault.hashicorp.com/role: "devwebapp"
        vault.hashicorp.com/agent-inject-secret-config.txt: "kv/secret/devwebapp/config"
      labels:
        app: orgchart
    spec:
      serviceAccountName: devwebapp
      containers:
        - name: orgchart
          image: jweissig/app:0.0.1
EOF

kubectl apply -f devwebapp.yaml

kubectl exec \
    $(kubectl get pod -l app=orgchart -o jsonpath="{.items[0].metadata.name}") \
    --container orgchart -- cat /vault/secrets/config.txt
