Kubernetes Policy

January 15, 2021

Page content

In this post I will show you how you can enforce best practices on Kubernetes Clusters.

Updated July 2021: Updated Features/Capabilities table. Notable change: Added “Self-service reports” comparison, the ability for non-policy admins to view policy violations (decoupled from policy objects).

Updated June 2021: Updated Features/Capabilities table. Notable changes: Kyverno now supports high availability and metrics.

Updated Aug 2021: Updated Features/Capabilities table. Notable changes: Kyverno now supports Image Signature Verification with Cosign

Parts of the K8S Security Lab series

For a production ready Kubernetes cluster it is very important to enforcing cluster-wide policies to restrict what a container is allowed to do. We do this wit PS in a previous pos. But how should we enforce our best practices to the cluster users?

OPA

Open Policy Agent (OPA), is a policy engine for Cloud Native environments hosted by CNCF. It is a general purpose policy engine. OPA policies are written in a Domain Specific Language (DSL) called Rego.

OPA Gatekeeper

Gatekeeper is specifically built for Kubernetes Admission Control use case of OPA. It uses OPA internally, but specifically for the Kubernetes admission control. Compared to using OPA with its sidecar kube-mgmt (aka Gatekeeper v1.0), Gatekeeper is integrated with the OPA Constraint Framework to enforce CRD-based policies and allow declaratively configured policies to be reliably shareable.

Install OPA Gatekeeper:

kubectl apply -f https://raw.githubusercontent.com/open-policy-agent/gatekeeper/master/deploy/gatekeeper.yaml

Now we need to create a policy template and a constraint that adds the variables to the template. If I want to create a policy to enforce all image comes from Only gcr.io, I need this Template:

apiVersion: templates.gatekeeper.sh/v1beta1
kind: ConstraintTemplate
metadata:
  name: k8srequiredregistry
spec:
  crd:
    spec:
      names:
        kind: K8sRequiredRegistry
      validation:
        # Schema for the `parameters` field
        openAPIV3Schema:
          properties:
            image:
              type: string
  targets:
    - target: admission.k8s.gatekeeper.sh
      rego: |
        package k8srequiredregistry
        violation[{"msg": msg, "details": {"Registry should be": required}}] {
          input.review.object.kind == "Pod"
          some i
          image := input.review.object.spec.containers[i].image
          required := input.parameters.registry
          not startswith(image,required)
          msg := sprintf("Forbidden registry: %v", [image])
        }

This template defines which parameters you need to define as well as the actual Rego code that will do the validation. Fo the constraint we specify that we need this constraint applied to Pods only and we pass the registry name that we need the images to be pulled from.

apiVersion: constraints.gatekeeper.sh/v1beta1
kind: K8sRequiredRegistry
metadata:
  name: images-must-come-from-gcr
spec:
  match:
    kinds:
      - apiGroups: [""]
        kinds: ["Pod"]
  parameters:
    registry: "gcr.io/"

Test the policy with an image from github:

kubectl run --generator=run-pod/v1 busybox1 --image=busybox -- sleep 3600

message: 'admission webhook "validation.gatekeeper.sh" denied the request: [denied
      by images-must-come-from-gcr] Forbidden registry: busybox'

Another great feature of OPA Gatekeeper is audit functionality, it enables periodic evaluations of replicated resources against the policies enforced in the cluster to detect pre-existing misconfigurations.

Audit results are stored as violations listed in the status field of the failed constraint.

kubectl describe policystrictonly.constraints.gatekeeper.sh policy-strict-constraint

OPA and Gatekeeper

You can deploy OPA kube-mgmt as both validating webhook as well as mutating webhook configurations. Whereas, Gatekeeper currently does not support mutating admission control scenarios.

Kyverno

Kyverno is a policy engine designed for Kubernetes. With Kyverno, policies are managed as Kubernetes resources and no new language is required to write policies. This allows using familiar tools such as kubectl, git, and kustomize to manage policies. Kyverno policies can validate, mutate, and generate Kubernetes resources. The Kyverno CLI can be used to test policies and validate resources as part of a CI/CD pipeline. (Source: Kyverno )

Install kyverno:

helm repo add kyverno https://kyverno.github.io/kyverno/
helm repo update
helm install kyverno --namespace kyverno kyverno/kyverno --create-namespace

Validate configurations

Here is an example of a Kyverno policy that validates that images are only pulled from gcr.io:

apiVersion : kyverno.io/v1alpha1
kind: Policy
metadata:
  name: check-registries
spec:
  rules:
  - name: check-registries
    resource:
      kinds:
      - Deployment
      - StatefulSet
    validate:
      message: "Registry is not allowed"
      pattern:
        spec:
          template:
            spec:
              containers:
              - name: "*"
                # Check allowed registries
                image: "*/gcr.io/*"

Here the kind is Policy not ClusterPolicy which means policies will only apply to resources within the namespace in which they are defined.

Mutate Configurations

Kyverno supports two different ways to mutate configurations. The first approach is to use a JSON Patch:

apiVersion : kyverno.io/v1alpha1
kind : Policy
metadata :
  name : policy-deployment
spec :
  rules:
    - name: patch-add-label
      resource:
        kinds :
        - Deployment
      mutate:
        patches:
        - path: /metadata/labels/isMutated
          op: add
          value: "true"

The other way to mutate resources based on conditionals that describes the desired state:

apiVersion: kyverno.io/v1alpha1
kind: Policy
metadata:
  name: set-image-pull-policy
spec:
  rules:
  - name: set-image-pull-policy
    resource:
      kinds:
      - Deployment
    mutate:
      overlay:
        spec:
          template:
            spec:
              containers:
                # if the image tag is latest, set the imagePullPolicy to Always
                - (image): "*:latest"
                  imagePullPolicy: "Always"

Generate Configurations

Policy rule can generates new configurations:

apiVersion: kyverno.io/v1alpha1
kind: Policy
metadata:
  name: "default"
spec:
  rules:
  - name: "deny-all-traffic"
    resource:
      kinds:
       - Namespace
      name: "*"
    generate:
      kind: NetworkPolicy
      name: deny-all-traffic
      data:
        spec:
        podSelector:
          matchLabels: {}
          matchExpressions: []
        policyTypes: []
        metadata:
          annotations: {}
          labels:
            policyname: "default"

Policy Reports

Kyverno policy reports provide information about policy execution and violations. Kyverno creates policy reports for each Namespace and a single cluster-level report for cluster resources.

$ kubectl get polr -A
NAMESPACE     NAME                  PASS   FAIL   WARN   ERROR   SKIP   AGE
default       polr-ns-default       338    2      0      0       0      28h
flux-system   polr-ns-flux-system   135    5      0      0       0      28h

$ kubectl get clusterpolicyreport -A
NAME                  PASS   FAIL   WARN   ERROR   SKIP   AGE
clusterpolicyreport   0      0      0      0       0      142m

$ kubectl describe polr polr-ns-default | grep "Status: \+fail" -B10
  Message:        validation error: Running as root is not allowed. The fields spec.securityContext.runAsNonRoot, spec.containers[*].securityContext.runAsNonRoot, and spec.initContainers[*].securityContext.runAsNonRoot must be `true`. Rule check-containers[0] failed at path /spec/securityContext/runAsNonRoot/. Rule check-containers[1] failed at path /spec/containers/0/securityContext/.
  Policy:         require-run-as-non-root
  Resources:
    API Version:  v1
    Kind:         Pod
    Name:         add-capabilities-init-containers
    Namespace:    default
    UID:          1caec743-faed-4d5a-90f7-5f4630febd58
  Rule:           check-containers
  Scored:         true
  Status:         fail
--
  Message:        validation error: Running as root is not allowed. The fields spec.securityContext.runAsNonRoot, spec.containers[*].securityContext.runAsNonRoot, and spec.initContainers[*].securityContext.runAsNonRoot must be `true`. Rule check-containers[0] failed at path /spec/securityContext/runAsNonRoot/. Rule check-containers[1] failed at path /spec/containers/0/securityContext/.
  Policy:         require-run-as-non-root
  Resources:
    API Version:  v1
    Kind:         Pod
    Name:         sysctls
    Namespace:    default
    UID:          b98bdfb7-10e0-467f-a51c-ac8b75dc2e95
  Rule:           check-containers
  Scored:         true
  Status:         fail

Comparison

OPA VS Kyverno

Features/Capabilities	OPA Gatekeeper	Kyverno
Validation	✓	✓
Mutation	alpha	✓
Generation	X	✓
Policy as native resources	Rego in CRD	✓
Metrics exposed	✓	✓
OpenAPI validation schema (kubectl explain)	X	✓
High Availability	✓	alpha
API object lookup	✓	✓
CLI with test ability	✓	✓
Policy audit ability	✓	✓
Self-service reports	X	✓
Image Signature Verification	X	✓
